Medium-Load Dual-Spectrum PTZ Camera

Brand Name : KAIDUN

Model Number : MCL-PT004

Place of Origin : China

MOQ : 1

Payment Terms : T/T

Supply Ability : 5000 units/year

Delivery Time : 5-8 week

Packaging Details : Wooden box packaging / cardboard box packaging

Thermal Resolution : 640*512

Thermal Length : 20-100mm zoom/15-75mm zoom optional

Visible Resolution : 4MP/8MP optional

Visible Focal Length : 40x/52x/55x optical zoom optional

Laser Range : 500m/800m/3000m optional

Power : DC24V,≤55W

Total Weight : ≤20kg

Dimensions : 315*245*475mm

Contact Now

Medium-Load Dual-Spectrum PTZ Camera
Key Features
  • The MCL-PT004 is a long range camera equipped with an observation-type thermal imaging lens
  • Spherical rotational structure allows for multi-angle observation with horizontal range of 0° to 360° and vertical range of -70° to +45°
Application Environment
Medium-Load Dual-Spectrum PTZ Camera
Forest Fire Prevention
Medium-Load Dual-Spectrum PTZ Camera
Army Border Guard
Medium-Load Dual-Spectrum PTZ Camera
The Army Defends the Coast
Medium-Load Dual-Spectrum PTZ Camera
Ships
Medium-Load Dual-Spectrum PTZ Camera
Shipping Port
Unlike manual zoom lenses, electric zoom lenses are used in a wide range of outdoor scenes covering extensive focal lengths. The focal length can be adjusted remotely to zoom in on important areas, providing excellent monitoring capabilities. With continuous development in the security industry and increased infrastructure investment, demand for electric zoom lenses has grown significantly in urban security, highways, railways, forest fire prevention, maritime management, ports, border defense, and oil fields.
Main Features
Material Aluminum Alloy (with powder coating)
Protection Class IP66
Working Temperature -40℃~+65℃
Working Humidity <90%
Video IP
Optional Matching Scheme Visible Lens + Thermal Lens
Visible Lens + Laser Lens
Visible Resolution 4MP/8MP optional
Visible Focal Length 40x/52x/55x optical zoom optional
Thermal Resolution 640*512
Thermal Length 20-100mm zoom/15-75mm zoom optional
Laser Range 500m/800m/3000m optional
Motor & Transmission Method Brushless DC Motor,Precision Spur Gear Transmission
Rotation Range Horizontal: 0~360° (0.23°~40.6°/s)
Vertical: -70°~+45° (0.23°~10.5°/s)
Function Top-mounted Payload (15KG),Gyro Stabilization, Optical Fog Penetratior Machine, Pedestrian, Non-motor Vehicle and Vessel Recognition
Voltage DC24V (≤55W)
Weight ≤20kg
Dimensions (H*L*W) 315*245*475mm
Mounting Formal Installation, Four-Point Base Fixation
Dimensions
Medium-Load Dual-Spectrum PTZ Camera
