Multi-Spectrum Small U-Turret Camera

Brand Name : KAIDUN

Model Number : MCL-PT008

Place of Origin : China

MOQ : 1

Payment Terms : T/T

Supply Ability : 5000 units/year

Delivery Time : 5-8 week

Packaging Details : Wooden box packaging / cardboard box packaging

Thermal Resolution : 640*512

Thermal Length : 50mm

Visible Resolution : 2MP

Visible Focal Length : 30x optical zoom

Laser Range : 500m

Rangefinder Range : 3000m

Power : DC24V,≤50W

Total Weight : ≤15kg

Contact Now

Multi-Spectrum Small U-Turret Camera
Key Features
  • The MCL-PT008 is a long range camera equipped with an observation-type thermal imaging lens,Laser and Rangefinder
  • Spherical rotational structure allows for multi-angle observation with horizontal range of 0° to 360° and vertical range of -60° to +70°
Application Environment
Multi-Spectrum Small U-Turret Camera
Forest Fire Prevention
Multi-Spectrum Small U-Turret Camera
Army Border Guard
Multi-Spectrum Small U-Turret Camera
The Army Defends the Coast
Multi-Spectrum Small U-Turret Camera
Ships
Multi-Spectrum Small U-Turret Camera
Shipping Port
Unlike manual zoom lenses, electric zoom lenses are used in a wide range of outdoor scenes covering extensive focal lengths. The focal length can be adjusted remotely to zoom in on important areas, providing excellent monitoring capabilities. With continuous development in the security industry and increased infrastructure investment, demand for electric zoom lenses has grown significantly in urban security, highways, railways, forest fire prevention, maritime management, ports, border defense, and oil fields.
Main Features
Material Aluminum Alloy (with powder coating)
Protection Class IP66
Working Temperature -40℃~+65℃
Working Humidity <90%
Video IP
Visible Resolution 2MP
Visible Focal Length 30x optical zoom
Thermal Resolution 640*512
Thermal Length 50mm
Laser Range 500m
Rangefinder Range 3000m
Bulid-in 2D Eletronic Compass
Motor & Transmission Method Torque Motor Direct Drive Method
Rotation Range Horizontal: 0~360° (0.09°~120°/s)
Vertical: -60°~+70° (0.09°~110°/s)
Function Top-mounted Payload (Self-locking 5KG),Gyro Stabilization, Optical Fog Penetratior
Voltage DC24V (≤50W)
Weight ≤15kg
Mounting Formal Installation, Four-Point Base Fixation
