Heavy-Load Dual-Spectrum PTZ Camera

Brand Name : KAIDUN

Model Number : MCL-PT006

Place of Origin : China

MOQ : 1

Payment Terms : T/T

Supply Ability : 5000 units/year

Delivery Time : 5-8 week

Packaging Details : Wooden box packaging / cardboard box packaging

Thermal Resolution : 640*512

Thermal Length : 30-150mm zoom

Visible Resolution : 4MP

Visible Focal Length : 86x optical zoom

Power : DC24V/48V,≤100W

Total Weight : ≤18kg

Dimensions : 343*387*215mm

Contact Now

Heavy-Load Dual-Spectrum PTZ Camera
Key Features
  • The MCL-PT006 is a long range camera equipped with an observation-type thermal imaging lens
  • Spherical rotational structure allows for multi-angle observation with horizontal range of 0° to 360° and vertical range of -55° to +60°
Application Environment
Heavy-Load Dual-Spectrum PTZ Camera
Forest Fire Prevention
Heavy-Load Dual-Spectrum PTZ Camera
Army Border Guard
Heavy-Load Dual-Spectrum PTZ Camera
The Army Defends the Coast
Heavy-Load Dual-Spectrum PTZ Camera
Ships
Heavy-Load Dual-Spectrum PTZ Camera
Shipping Port
Unlike manual zoom lenses, electric zoom lenses are used in a wide range of outdoor scenes covering extensive focal lengths. The focal length can be adjusted remotely to zoom in on important areas, providing excellent monitoring capabilities. With continuous development in the security industry and increased infrastructure investment, demand for electric zoom lenses has grown significantly in urban security, highways, railways, forest fire prevention, maritime management, ports, border defense, and oil fields.
Main Features
Material Aluminum Alloy (with powder coating)
Protection Class IP66
Working Temperature -40℃~+65℃
Working Humidity <90%
Video IP
Visible Resolution 4MP
Visible Focal Length 86x optical zoom
Thermal Resolution 640*512
Thermal Length 30-150mm zoom
Motor & Transmission Method Brushless DC Motor,All-Metal Worm Gear Gimbal Reducer
Rotation Range Horizontal: 0~360° (0.23°~30°/s)
Vertical: -55°~+60° (0.3°~13°/s)
Function Top-mounted Payload (Self-locking 35KG), Gyro Stabilization, Optical Fog Penetration
Voltage DC24V/48V (≤100W)
Weight ≤18kg
Dimensions (H*L*W) 343*387*215mm
Mounting Formal Installation, Four-Point Base Fixation
