High-temperature Resistant Semiconductor Refrigeration Camera

Name: Hightemperature Resistant Semiconductor Refrigeration Camera
Brand: KAIDUN
Price: 1 USD

Brand Name : KAIDUN

Model Number : KDG013

Place of Origin : China

MOQ : 1

Payment Terms : T/T

Supply Ability : 5000 units/year

Delivery Time : 5-8 week

Packaging Details : Wooden box packaging / cardboard box packaging

Visible Resolution : 2MP/4MP optional

Visible Focal Length : 4-20mm/3-10mm High-temperature Resistant Manual Lens

Operating Conditions : Temperature inside the furnace ≤ 1000°C

Dust Concentration in the Operating Environment : ≤ 200 mg/m3 (based on cement dust as the standard)

Power : DC12V/POE optional

Total Weight : ≤30kg

Contact Now

High-temperature Resistant Semiconductor Refrigeration Camera

Key Features

The KDG013 is a High-temperature Camera Equipped with an Air-cooled housing
The camera lens of this system equipment can be directly extended to the observation hole on the furnace wall to monitor the operation of workpieces inside the furnace, as well as the conditions of materials, flame shape,and other related situations.

Application Environment

High-temperature Resistant Semiconductor Refrigeration Camera

Metallurgical & Steel Industry

Power Generation Industry

Petrochemical & Chemical Industry

Glass & Ceramic Industry

Waste Incineration & Environmental Protection

High-temperature resistant cameras are engineered to operate reliably in extreme thermal environments (typically -40°C to 1200°C, depending on models) where standard cameras fail due to overheating, component degradation, or structural damage.

Main Features

Material	304 Stainless Steel + Local High-temperature Resistant Pot
Operating Conditions	Temperature inside the furnace ≤ 1000℃
Dust Concentration in the Operating Environment	≤ 200 mg/m3 (based on cement dust as the standard)
Video	IP
Visible Resolution	2MP/4MP etc
Visible Focal Length	4-20mm/3-10mm High-Temperature Resistant Manual Lens
Cooling Method	Combined Air-Water Cooling for Temperature Reduction
Comperssed Air Pressure	0.2~0.4Mpa
Compressed Air Flow Rate	0.3~0.7m³/min(0.7 m³/min at an air pressure of 0.4 MPa)
General Function	Anti-flicker, Dual Stream, Rotation,Heartbeat, Mirroring, Password-protected Video Masking,Watermarking Technology,IP Address Filtering
Intelligent Alarm	Cross-line Detection; Region Intrusion Detection;Motion Detection; Dynamic Analysis Tampering Alarm;Network Cable Disconnection;IP Address Conflict; Unauthorized Access
Voltage	DC12V/POE optional
Dimensions	1130372190mm
Weight	≤30kg
Mounting	Weld together with the matching mounting base plate to the reserved hole of the fumace.
